UV-int 159
+ UV-intensity :0-2000mW/cm2
+ UV-dose :0-36000mJ/cm2
+ Temperature:0-120C

UV-int159
The UV-int159 is a high quality UV measuring instrument. It is used to measure UV energy of different light sources, especially on printing machines. It was specially designed with a recess in the housing for better handling. It is ideal to ensure quality control of printing and drying processes.By addition of the incidence of the light quantities during the exposure cycle, relative values are calculated.Because of uneven radiation distribution of the UV light source and different type of construction of the measuring devices by different manufacturers,
different readings may appear under the same measurement conditions.

Technical Data:

UV-int159

Spectral range: UV 250 - 410 nm (Max:365nm)

Max. Power Input 0 to 5,000 mW/cm2

Display: LCD, 2x16 digits

Display range: 0 to 36,000 mJ/cm2

Measuring range: 0 to 2,000 mW/cm2

Measuring temperature: 32 to 230 F / 0 to 115 C

>>>more



Sampling rate: 0.01 sec (100/sec)

Recording cycle: 120 sec.

Power source: 2 x AAA

Battery service life: 2,000 measurements

Dimensions: 120 x 13 mm (4.7 x 0.5")

Weight: approx. 7 ounce (200 g)

Base Accuracy: 5 %




While on the conveyer belt, the UV-Int159 can withstand max. 110 Centigrade for up to 10seconds.

A special AUTO-OFF feature that turns off the unit automatically after one minute serves as energy saving and extension of the battery service life. >>>more
